DCP (ABC) Stored Pressure Type Fire Extinguishers
Make Dry Powder extinguishers are characterized by their high performance, simple method of operation and rapid fire knock down capability. They are suitable for tackling fires involving freely burning materials, petrol & oils, gas & electrical equipment. They are ideal for vehicle & marine risks.
Capacity: 1kg, 2kgs, 4kgs, 6kgs, 9kgs
Charge: Sodium-bicarbonate based Dry Chemical agent capable of fighting class B, C & E fires
Accessories: Wall mounting brackets, hose, belt.
Technical Specification
| Fire Extinguisher Capacity | 1 KG | 2 KG | 4 KG | 6 KG | 9 KG |
|---|---|---|---|---|---|
| Minimum Period for Which | (IS-15683) | (IS-15683) | (IS-15683) | (IS-15683) | (IS-15683) |
| Throw of Jet Maintained | 8 sec | 8 sec | 16 sec | 20 sec | 25 sec |
| Minimum Period to Discharges | |||||
| At Least 90% of Contents | 12 sec | 16 sec | 20 sec | 25 sec | 30 sec |
| Range. WT Approx | 2 mtrs | 3 mtrs | 4 mtrs | 6 mtrs | 7 mtrs |
| Empty WT. Approx | 1 kg | 2.3 kg | 2.75 kg | 3.3 kg | 5.35 kg |
| Full WT. Approx | 2 kg | 3.3 kg | 6.75 kg | 9.3 kg | 14.35 kg |
| Fire Rating | 1 A, 8 B | 1 A, 8 B | 1 A, 13 B | 2 A, 21 B | 2 A, 34 B |
| Working Pressure | 15 KGF/CM2 | 15 KGF/CM2 | 15 KGF/CM2 | 15 KGF/CM2 | 15 KGF/CM2 |
| Hydro Pressure | 35 KGF/CM2 | 35 KGF/CM2 | 35 KGF/CM2 | 35 KGF/CM2 | 35 KGF/CM2 |
| Bursting Pressure | 55 KGF/CM2 | 55 KGF/CM2 | 55 KGF/CM2 | 55 KGF/CM2 | 55 KGF/CM2 |
